PerforMax High Speed Door

Commercial Installation

August 2020

Performax High Speed Door-

High Speed Security Rubber Roll-up Door

Springless Drive System: Direct drive motor. No counterweights, tension springs, hinges, pulleys, straps, or drums. Black SBR Rubber Curtain: 1/4" thick two-layer SBR and high strength polyester fabric. Limited Lifetime Warranty

Windtab Design: PerforMax windtab design produces a high quality seal. HDPE windlocks and guide rails provide low friction operation.

Heavy Duty Construction: Heavy duty powder-coated steel side columns, roll-tube, two spreader bars, head plates and bottom bar. Exposed items powder-coated safety yellow standard and other colors available upon request. Stainless steel construction also available upon request.

MaxSpeed Controller: The PerforMax controller offers multiple inputs for activation exibility. Requires 460/230 Volt 3 Phase power.

Speed: Variable speed soft start/soft stop operation. Opening speed of up to 24" per second.

Breakaway Design: Doors can be reset after impact in most cases with no tools needed.

Photo Eye: One (1) photo eye is standard. Light curtain optional.

Bottom Bar & Reversing Edge: PerforMax includes a breakaway bottom bar and wireless reversing safety edge (self-monitored) as standard.
